Synthetic XDP Grease

  • Base Oil Technology: Synthetic
  • NLGI: #1.5
  • Base Oil Viscosity: 400-680
  • Thickener: Calcium Sulfonate

AMSOIL Industrial Synthetic Extreme-Duty Performance (XDP) Grease is specifically engineered to provide superior mechanical stability in large, slow-speed, high-load wind turbine main bearings. Its unique combination of synthetic base oils, calcium-sulfonate thickeners and advanced additives fight base oil bleed and grease thickening to provide exceptional longterm wear and corrosion protection in outdoor environments and other severe-service industrial applications.

  • Superior mechanical stability for extended severe-service and extreme-pressure wear protection.
  • Exceptional protection against corrosion from condensation, water ingress and operation in wet environments.
  • Protects bearings from fluctuating wind speed and from fretting at inoperable times.
  • Maintains consistency, providing exceptional long-term bearing protection and improved efficiency.
  • Outstanding cold-flow properties for easy startups and efficient equipment operation at low temperatures.
  • Excellent thermal and oxidative stability at high temperatures.





See how AMSOIL Industrial Synthetic XDP Grease compares against the rest of our grease family.



Non-rotating Bearings and Sliding Applications

General Purpose/Rotating Bearings

Specialty/Food-Grade

Lithium



Calcium Sulfonate

Other







Typical Technical Properties*

AMSOIL Industrial Synthetic XDP Grease

Test



XDP460

XDP680

Thickener Type



Calcium sulfonate

Calcium sulfonate

NLGI Consistency Grade ASTM D445 1.5 1.5
Operating range °C (°F) ASTM D445 -30 to 160 (-22 to 320) -30 to 160 (-22 to 320)
Base Oil Viscosity, 40°C ASTM D445

400

680

Penetration, worked 60 strokes

ASTM D217

301

296

Penetration, worked 10,000 strokes

ASTM D217

310

306

Dropping Point, °C (°F)

ASTM D2265

>318 (>604)

>316 (>600)

Four-Ball Wear Test, Scar, mm

ASTM D2266

0.42

0.41

Four-Ball EP Weld Point, kgf

ASTM D2596

400

500

Fretting Wear, mg

ASTM D4170

4

3.75

Water Washout, %

ASTM D1264

0.0

1.57

Oil Separation, % loss

ASTM D6184

1.00

0.0

Rust and Corrosion

ASTM D1743

Pass

Pass

Copper Corrosion

ASTM D130

1b



1b



Low-Temperature Torque, -40°C, N•m Starting

ASTM D4693

0.79

0.58

Running   0.13 0.21
Color



Tan

Tan

*Technical properties are general characteristics of the product and not manufacturing specifications. Variations that do not affect product performance should be expected. Product formulations are subject to change without notice. Customers are responsible for determining product suitability for use with their equipment.
